MSCSM120TAM11CTPAG
Microchip Technology
Microchip Technology
PM-MOSFET-SIC-SBD~-SP6P
$1,138.84
Available to order
Reference Price (USD)
1+
$1138.84000
500+
$1127.4516
1000+
$1116.0632
1500+
$1104.6748
2000+
$1093.2864
2500+
$1081.898
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
| DHL / Fedex / UPS | 2-5 days |
| TNT | 2-6 days |
| EMS | 3-7 days |
Microchip Technology MSCSM120TAM11CTPAG is available at inksontech.com. We only sale New&Original Part and offer 1 year warranty time. If you would like to know more about the products or apply more better price, please send a quote to us or contact us by email.
Experience hassle-free transactions with our flexible payment options and credit facilities. Learn more about the various payment methods accepted, installment plans, and any exclusive credit offers available to make your shopping experience seamless.
MSCSM120TAM11CTPAG
$1,138.84
Product details
The MSCSM120TAM11CTPAG by Microchip Technology is a top-tier MOSFET array in the Discrete Semiconductor Products category, specifically designed for Transistors - FETs, MOSFETs - Arrays. This product is perfect for applications requiring high power efficiency and compact design, offering exceptional performance and reliability.\n\nKey attributes of the MSCSM120TAM11CTPAG include minimal conduction losses, high switching speed, and superior thermal management. The array configuration allows for efficient use of PCB space while maintaining high performance. Its design ensures compatibility with a variety of driving circuits, making it highly versatile.\n\nIdeal applications include robotics, consumer electronics, and aerospace systems. In robotics, it provides precise motor control and power management. Consumer electronics benefit from its efficiency and compact size. Aerospace systems rely on its reliability under extreme conditions.\n\nEnhance your designs with the MSCSM120TAM11CTPAG. Contact us for pricing and availability details. Our experts are ready to help you find the perfect solution for your needs.
General specs
- Product Status: Active
- FET Type: 6 N-Channel (3-Phase Bridge)
- FET Feature: Silicon Carbide (SiC)
- Drain to Source Voltage (Vdss): 1200V (1.2kV)
- Current - Continuous Drain (Id) @ 25°C: 251A (Tc)
- Rds On (Max) @ Id, Vgs: 10.4mOhm @ 120A, 20V
- Vgs(th) (Max) @ Id: 2.8V @ 3mA
- Gate Charge (Qg) (Max) @ Vgs: 696nC @ 20V
- Input Capacitance (Ciss) (Max) @ Vds: 9060pF @ 1000V
- Power - Max: 1.042kW (Tc)
- Operating Temperature: -40°C ~ 175°C (TJ)
- Mounting Type: Chassis Mount
- Package / Case: Module
- Supplier Device Package: SP6-P
