ADG821BRMZ
Analog Devices Inc.
Analog Devices Inc.
IC SWITCH DUAL SPST 8MSOP
$3.96
Available to order
Reference Price (USD)
1+
$3.43000
50+
$2.90880
100+
$2.52100
500+
$2.14604
1,000+
$1.80992
2,500+
$1.71942
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
| DHL / Fedex / UPS | 2-5 days |
| TNT | 2-6 days |
| EMS | 3-7 days |
Analog Devices Inc. ADG821BRMZ is available at inksontech.com. We only sale New&Original Part and offer 1 year warranty time. If you would like to know more about the products or apply more better price, please send a quote to us or contact us by email.
Experience hassle-free transactions with our flexible payment options and credit facilities. Learn more about the various payment methods accepted, installment plans, and any exclusive credit offers available to make your shopping experience seamless.
ADG821BRMZ
$3.96
Product details
Introducing the ADG821BRMZ multiplexer/demultiplexer IC from Analog Devices Inc., a versatile solution for complex signal routing challenges. This high-performance component in the Interface category offers configurable channel options with exceptional signal integrity. Its design features low glitch energy during switching transitions, critical for precision applications. The device supports wide bandwidth signals while maintaining excellent linearity characteristics. Common implementations include laboratory instrumentation, wireless base stations, and automotive telematics systems. With its robust ESD protection and wide operating temperature range, the ADG821BRMZ performs reliably in harsh environments. The IC's low standby current makes it suitable for battery-powered applications. Analog Devices Inc. provides comprehensive design resources, including evaluation kits and application notes. For detailed product information or to discuss your specific application needs, visit our product page. Submit your inquiry online to receive prompt assistance from our technical sales team and access to volume pricing options.
General specs
- Product Status: Active
- Switch Circuit: SPST - NO
- Multiplexer/Demultiplexer Circuit: 1:1
- Number of Circuits: 2
- On-State Resistance (Max): 600mOhm
- Channel-to-Channel Matching (ΔRon): 160mOhm
- Voltage - Supply, Single (V+): 1.8V ~ 5.5V
- Voltage - Supply, Dual (V±): -
- Switch Time (Ton, Toff) (Max): 45ns, 16ns
- -3db Bandwidth: 24MHz
- Charge Injection: 15pC
- Channel Capacitance (CS(off), CD(off)): 85pF, 98pF
- Current - Leakage (IS(off)) (Max): 250pA
- Crosstalk: -82dB @ 1MHz
- Operating Temperature: -40°C ~ 125°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
- Supplier Device Package: 8-MSOP
